BSP threaded PPGF flange, DIN/ANSI/BS slotted

Katalogový list

Popis

* DIN = EN1092-1 PN10 ANSI = ASME B16.5 Class 150
BSP threaded PPGF flange, DIN/ANSI/BS slotted
d
(mm) 		DN
(mm) 		DN
(inch) 		A
(mm) 		B
(mm) 		C
(mm) 		d
(mm) 		Obj.kód
 Poptávka
32
25
1''
115.5
22.5
16
26
2042-02O
40
32
1''1/4
140
27.5
18
32
2042-03O
50
40
1''1/2
150
31.5
18
40
2042-04O
63
50
2''
165
42
18.5
50
2042-05O
